Muffle furnace (Nabertherm L 9/12 with B510)

High Performance Muffle Furnace L(T)9/12/B510 with maximum operation temperature of 1200°C and capacity of 9L. The L(T)9/12/B510 models have been proven popular for daily laboratory use, such as metal heat treatment, catalysts, etc.. They stand out for their excellent workmanship, advanced and attractive design, and high level of reliability. The muffle furnaces come equipped with either a flap door or lift door.

• Tmax 1200°C
• Heating from two sides by ceramic heating plates for an optimal temperature uniformity
• Thermocouple type: type S
• Ceramic heating plates with integral heating element which is safeguarded and easy to replace
• Optional flap door (Model: L) which can be used as work platform or lift door (Model: LT) with hot surface facing away from the operator
• Adjustable air inlet integrated in door
• Exhaust air outlet in rear wall of furnace
• Controller B510 (5 programs with each 4 segments) / C550 (10 programs with each 20 segments)
